Control membrane LEDs and Trigger Button

7. Control membrane LEDs and Trigger Button​

control-membrane

info

Note - (if you have followed the Software setup page you can skip this step)

Before you can address the membrane, you will need to activate the i2c_vc interface. To do that you need to run the following command:

echo "dtparam=i2c_vc=on" | sudo tee -a /boot/config.txt

After this you need to reboot the pi, sudo reboot will do the job.

Download the below file to control membrane LEDs and trigger buttons.​
